Trim Strip white - Pack of 2 m

• Type: Fender Blackface Style Knob
• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 30 x 16,1 mm
• Mounting: Set-Screw

Set of metal corners for housing consisting of:

• 8 x Cabinet corner w/ cutaway 2 leg, silver (ah4023)
• Steel nickel plated
• Internal radius: 12 mm
• 16 x Screws with extra flat head, silver

Fender Strap Handle

• Fender #0990947000
• Plastic covered with steel inner core
• End plates: Steel, nickel plated
• Color: Black
• Mounting hardware: Screws and t-nuts included

Strap Handle Heavy Duty

• Plastic covered with steel inner core
• End plates: Steel, nickel plated
• Color: Black
• WITHOUT MOUNTING HARDWARE

• Size: ca. 60 x 90 cm (only available in this size)
• ORIGINAL FENDER
• Material: 100% Polypropylen
• Price per pcs.
• Actual shades may vary.

Further information and notes on Grillcloth

• FAQ Grillcloth

The LNDVerb kit is based on a classic Fender reverb circuit, but uses LND 150 Mosfets instead of tubes. These can be operated at voltages as high as 500 V, to get as close as possible to the characteristics of real tubes.

The kit can be integrated into an existing amplifier or can be build as standalone unit like the Fender tube reverb.

The unit needs less than 10 mA current, so a VPump for example can be used as power supply in a standalone build. If it gets integrated into an existing amplifier the already present power supply of the amp can be used to supply the needed voltage for the unit without the need to upgrade the power transformer.

A reverb transformer of the type 125A20B or similar and a reverb tank are necessary to operate the LNDVerb. These are both not included in the kit.

The needed RCA phone sockets and potentiometers are included in the kit.

Further informations and examples of the finished unit can be found in the PDF below.

Matching parts are linked below and can be ordered with the unit if needed.

Files:

• Datasheet



• Springs: 3
• Delay Type: medium
• Size: short (9 ¼" / 23,5 cm)
• Input Impedance: 800 Ohms
• Output Impedance: 2575 Ohms
• Mounting: Horizontal Open Side Down
• Connectors: Input Insulated - Output Grounded
• Accutronics by Accu-Bell, Made in Korea

Suitable for these amplifiers Fender® Blues Jr., Deluxe 90, Princeton 65, Stage Series, Acoustasonic Junior, Vaporizer, Ultimate Chorus, Ultra Chorus, Sidekick Keyboard 60, Sidekick Reverb 35, Super 60, Super 112, Frontman 65R, Eighty-Five, Tech 21® Trademark 30, Epiphone® Valve Junior Hot Rod, Vox® AC15CC, AC15C, Peavey® Envoy 110, Ultra 60/120, Backstage, Valveking and similar models.




Panel Mount Potentiometer

• Power Rating: 0,125 W
• Voltage Rating: 150 V AC
• Tolerance: 20%
• Shaft: 6,3 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: M7 (6,8 mm)
• Termination: Solder lugs
• Dimension: 16 mm

Panel Mount Potentiometer

• Power Rating: 0,125 W
• Voltage Rating: 150 V AC
• Tolerance: 20%
• Shaft: 6,3 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: M7 (6,8 mm)
• Termination: Solder lugs
• Dimension: 16 mm
