Tolex VOX®-Style Fawn

PVC piping for baffles and front panels

• Clear with metal Tinsel
• Marshall style
• Size 4.8 x 10 mm
• 4 m piece

• Rubber foot with steel insert
• Size: d = 38 mm, h = 20 mm
• Pack of 4
• Screws included

for the use with two 8 Ohm speakers the following configurations are possible:

• 4 ohm mono
• 8 ohm left + 8 ohm right stereo
• 8 ohm left only mono
• 8 ohm right only mono
• 16 ohm mono

Round dish / ferrule for 6.3 mm jack

• metal
• black powder coated
• incl. 3 screws

• 6,3 mm jack
• mono
• Installation diameter: 10 mm

Files:

• Datasheet

Empty amplifier housing for TT-Chassis #030
The headshell is made of 18 mm Pine Plywood and can be painted or tolexed by the customers to their own ideas. The front and back panel and the holders are not assembled but included. They can get assembled if needed (woodglue is included).
Hardware, such as corners, handles or feet are NOT included.

Note: the side brackets inside are NOT needed when using chassis 036 - model 2020.

Specifications

• Size: 510 x 240 x 240 mm (Outside)
• Hardware: Screws are included.
• Weight: ca. 4 kg
• Wood: 18 mm Pine Plywood
• Dovetail joints
• Made in Germany

• Springs: 2
• Delay Type: long
• Size: long
• Replacement: Fender, Marshall, Ampeg "F"
• corresponds to Fender part number 006-4063-049
• Accutronics by Accu-Bell, Made in Korea

Aluminium Chassis 035 for the TT Surfmate Kit

• 2 mm Aluminium
• predrilled
• made for the TT Surfmate kit
• 3 x noval, 1 x octal
• Mounting: with cage nuts (not included)

• Datasheet

Surf at the maximum !

Set of componentes for building the TT Surfmate. Please visit the >>Project page for more infos about the amp.

INCLUDED:

• Transformers (Power and Output)
• Resistors
• Capacitors
• Jacks
• Light
• Wires
• Board
• Switche
• PSU
• Tubes
• Fuses & Fuesholder

NOT INCLUDED:

• Knobs
• Chassis
• Faceplate
• REVERB TANK

To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it than don't build it.

Set of metal corners for housing consisting of:

• 8 x Cabinet corner w/ cutaway 2 leg, silver (ah4023)
• Steel nickel plated
• Internal radius: 12 mm
• 16 x Screws with extra flat head, silver
