Tesla Optocoupler 3WK 163 40

Mobile Preview: Tesla Optocoupler 3WK 163 40

Description

UIO (kV~): 2.5
RIO (O): 1010
CIO (pF): 0.5
Clim. Category: 40/ 70/ 04
Crossreference: Vactrol VTL5C1, Moririca MCD 735
