Swivel & braked wheel castor

• Self tap screw
• flange head
• DIN 968
• 4.5 x 19 mm, black
• Extra Flat - ideal for the mounting of the corners

LND150N3-G - MOSFET

• Transistor Polarity: N-Channel
• Drain-Source Breakdown Voltage: 500V
• Gate-Source Breakdown Voltage: +/- 20 V
• Continuous Drain Current: 30 mA
• Case: TO-92
• ROHS: Yes

Files:

• Datasheet

2 Tubes, matched as Pair

The high-quality TTEL84/6BQ5 tube with 12 watts of power is perfect for guitar, bass, and audio amplifiers. Inspired by classic NOS EL84 models, this tube is manufactured using modern production methods to ensure consistent high quality.

It offers an ideal combination of sound and reliability and is a direct replacement for all EL84 or 6BQ5 tubes.

Specifications

Electrical Specifications

• Type: Pentode
• Base: Noval (B9A)
• Heater Voltage: 6.3 V (min 5.8 V / max 7.7 V)
• Heater Current: approx. 0.76 A
• Anode Dissipation: 12 W
• Screen Grid Dissipation: 2 W

Operating Conditions

• Anode Voltage (Va): max. 300 V
• Screen Grid Voltage (Vg2): max. 300 V
• Grid Bias Voltage (Vg1): -7.3 V (typical for Class-A operation)
• Anode Current (Ia): 48 mA (at -7.3 V grid bias)
• Screen Grid Current (Ig2): 5 mA

Characteristic Curves

• Amplification Factor (μ): approx. 20
• Internal Resistance (Ra): approx. 38 kΩ
• Transconductance (S): 11 mA/V

Mechanical Specifications

• Length: approx. 70 mm (without pins)
• Diameter: approx. 22.5 mm
• Weight: approx. 25 g

Typical Applications

• Class-A Amplifier: 5.7 W output power at 250 V Anode voltage, 48 mA Anode current
• Class-AB Amplifier: 17 W output power at 300 V Anode voltage, 48 mA Anode current per tube (Push-Pull configuration)

Pinout

1. g1 (Control Grid)
2. k, g3 (Cathode, Screen Grid)
3. h (Heater)
4. h (Heater)
5. a (Anode)
6. • (no connection)
7. • (no connection)
8. g2 (Screen Grid)
9. g3 (Screen Grid)

Usage Notes

• Operating Temperature: Should be operated in a well-ventilated enclosure to prevent overheating.
• Interchangeability: EL84 can be replaced by the Russian 6П14П or American 7189, taking into account different specifications.

Mounting kit for all TT-Chassis which are designed for mounting with cagenuts and 19" housings

Included are:

• 4 x cagenut M6
• 4 x thread screw M6 x 30

Polyester Film Capacitors

• Voltage Rating: 630 V
• Tolerance: +/- 10%
• Operating Temperature Range:c- 55°C / + 125 °C
• Termination Style: radial

Faceplate for TT Amp-Kit Lummerland Express - black/white

• Color: #C01 black / white
• Material: 1.5 mm Transply
• Front and rear panel

Files:

• Template

Width ca. 135 cm
Price per linear meter.
Actual shades may vary.
We ship the tolex as one piece if you order more than 1 meter.

Material:
80% PVC Film
20% Poly-Cotton Fibre

REACH compliant

Please note !
when you order more than 1 m and select Deutsche Post / DHL Parcel (Not DHL Express) we need to cut the width of the tolex to ca. 115 cm. Otherwise it is not possible to ship the tolex with DHL because the parcel length would exceed the maximum parcel length.
