Knob Contempo, cream

• Type: HV ceramic disk capacitor
• Epoxy resin molding
• (insulating and flame retardant)
• Voltage Rating: 2 kV
• Tolerance: - 10 %
• Operating Temperature Range: - 30°C / + 85 °C
• Grid: 7,5

• Type: Electrolytic capacitor
• Capacitance: 1 µF
• Voltage Rating: 350 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 7 mm x 27 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

• Type: HV ceramic disk capacitor
•   Epoxy resin molding
•   (insulating and flame retardant)
• Voltage Rating: 500 VDC
• Tolerance: - 20 % / +50 %
• Operating Temperature Range: - 40°C / + 85 °C
• Diameter: 6 mm
• Grid: 5

• Voltage Rating:    500 V
• Tolerance: 5%
• Operating Temperature Range: - 50°C / + 150°C
• Termination Style: radial

• Voltage Rating:    500 V
• Tolerance: 5%
• Operating Temperature Range: - 50°C / + 150°C
• Termination Style: radial

• Voltage Rating:    500 V
• Tolerance: 5%
• Operating Temperature Range: - 50°C / + 150°C
• Termination Style: radial

Screw set for Torodial-Transformers

1 x Screw M5*60 mm
1 x Screw Lock Nut M5
2 x Washer M5

suitable for this TT Transformers:

tt-t106
tt-t107
tt-t185
tt-t244

• Type: Bridge Rectifier
• Max. alternating input voltage: 500 V
• Repetitive peak reverse voltage: 1000 V
• Peak forward surge current  IFSM 50/55 A
• Repetitive peak forward current  IFRM  10 A
• Junction temperature: –50 to +150 °C
• Size: 19 x 3,5 x 10 mm

Kit of an active, serial tube-driven FX-Loop (with parallel option) for a subsequent installation in an existing tube amplifier
The FX-Loop works with one 6112 miniature tube in the send and in the return stage. The send and return level can be adjusted to their optimal value with two potentiometers. The Loop works with the present high voltage of the amplifier.
It has two inputs for low and high signal levels.

Input Levels:
InA: 30 - 60 Vpp, max. 65 Vpp
InB: 10 - 15 Vpp, max. 18 Vpp

Heater:
6,3 V @ 300 mA

The FX-Loop utilize POTENTIALLY FATAL HIGH VOLTAGES.
Seek help from a competent technician if you are in any way unfamiliar with high voltage circuits.
Use at your own risk.

Files:

• Documentation
• Documentation - OLD

• Size: 6.3 mm 1/4"
• Poles: 3-pole, stereo
• Design: open, chassis-mount
• Connection type: solder connections
• Housing: metal
• Manufacturer: Rean (by Neutrik)

Files:

• Datasheet
