JJ EL84 / 6BQ5 Red Label - SINGLE

Kit for TT PSU Mini

The kit includes all components except a powertransformer and a choke for building PSU for tube amps. If you want to use a choke instead of the 5 W resistor than you must order the choke that you need separately.
The PSU can handle max 700 V DC at out B1 and B2, 450 V DC at out B3 and is recommended for tube amps up to 50 Watt. The size of the PSU is 97 x 55 mm only and has a high of ca. 40 mm.

Please refer the attached schematic for more infos about the layout and design of the PSU.

Tip: use Duncanamps' PSU Designer to simulate and calculate power supplies.

Files:

• Document

• Much easier, faster and saver than with a tag board
• optional connection for FX-Loop

Active, serial FX-Loop for a subsequent installation in an existing tube amplifier
The FX-Loop works with  two LND150 in the send and in the return stage. The send and return level can be adjusted to their optimal value with two potentiometers. The Loop works with the present high voltage of the amplifier.
It has two inputs for low and high signal levels.

Input Levels:
InA: 30 - 60 Vpp, max. 65 Vpp
InB: 10 - 15 Vpp, max. 18 Vpp

The FX-Loop utilize POTENTIALLY FATAL HIGH VOLTAGES.
Seek help from a competent technician if you are in any way unfamiliar with high voltage circuits.
Use at your own risk.

Files:

• Documentation

Retainer for EL84 / EL844Tubes
