JJ 16+16 µF @ 500 V

• Type: Metalfilm Resistor
• Power: 0,4 Watt
• Voltage: 350 V / 500 VDC Overload
• Tolerance: 1%
• Surface temperature: max. 125 °C
• Temperature coefficient: TC ±50
• Dimensions:    6,3 mm x 2,5 mm
• Termination Style: axial
• RoHS compliant: Yes

Active, serial FX-Loop for a subsequent installation in an existing tube amplifier
The FX-Loop works with  two LND150 in the send and in the return stage. The send and return level can be adjusted to their optimal value with two potentiometers. The Loop works with the present high voltage of the amplifier.
It has two inputs for low and high signal levels.

Input Levels:
InA: 30 - 60 Vpp, max. 65 Vpp
InB: 10 - 15 Vpp, max. 18 Vpp

The FX-Loop utilize POTENTIALLY FATAL HIGH VOLTAGES.
Seek help from a competent technician if you are in any way unfamiliar with high voltage circuits.
Use at your own risk.

Files:

• Documentation

• Specification: ½ Watt, axial
• Temperature Range: -55°C to +125°C
• Tolerance: 10%
• Max. Operating Voltage: 350 V
• Size: l=9.5 mm, d=3.6 mm

• Capacitance: 30 µF
• Voltage Rating: 500 V
• Tolerance: -10 % / +30 %
• Operating Temperature Range: - 25°C / + 70 °C
• Dimensions: Ø 25 mm x 42 mm
• Termination Style: axial leads

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 8 + 8 µF
• Voltage Rating: 450 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 25 mm x 39 mm
• Termination Style: axial

Mixed sizes, length 10 cm / ea, black

• 30 x 1,5mm Ø
• 30 x 2,5mm Ø
• 20 x 4mm Ø
• 10 x 6mm Ø
• 6 x 10mm Ø
• 4 x 13mm Ø

• solid tinned copper wire
• Wire diameter: 0.8 mm
• Cross-section: 0.5 mm²
• Outer diameter: 1.4 mm
• PVC insulation
• Rated voltage: max.: 900 V
• Temperature range: –15 °C to +70 °C
• Length: 100 m

Mixed sizes and colors, length 10 cm / ea

• 30 x 1,5mm Ø
• 30 x 2,5mm Ø
• 20 x 4mm Ø
• 10 x 6mm Ø
• 6 x 10mm Ø
• 4 x 13mm Ø

In plastic box

• Termination Style: Axial
• Power Rating: 5 W
• Tolerance: 5 %
• Temperature Coefficient: 350 PPM / C
• Operating Temperature min/max: - 55 C / + 155 C
• Voltage Rating: 500 V
• Diameter: 8,5 mm
• Length: 25 mm
• Lead Diameter:  0.75 mm

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 33 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

• Electrolytic capacitors, insulated aluminum can
• Capacitance: 22 µF
• Voltage Rating: 63 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 6 mm x 10 mm
• Termination Style: axial
• Mallory Vishay

Images are for reference only. See Product Specifications
