High Power Resistor 12R / 150 Watt

Coloration : Nice warm, fat tone with a little top end bite and clarity. Very touch-sensitive with a hint of British flavor
Genre : American Rock, Blues, and Southern Rock

Specifications

• Nominal Diameter: 12 " / 304.8 mm
• Voice Coil: 2 " / 50.8 mm
• Overall diameter: 305.3 mm
• Pitch Circle Diameter: 295.4 mm
• Section Diameter: 278.6 mm
• Diameter of fixing holes: 6.4 mm
• Depth: 130 mm
• Nominal Impedance: 8 Ohm(s)
• Nominal Load Capacity: 150 W
• Sensitivity (1 W / 1 m): 99 dB
• Frequency response: 70 - 5000 Hz
• Voice Coil Material: copper
• Magnet: Ferrite
• Depth of the magnetic gap: 7.92 mm

Thiele & Small Parameter

• Fs (Resonance Frequency): 79 Hz
• Re (DC resistance): 7.3 Ohm(s)
• Qms (mechanical quality): 13.88
• Le (inductance of the voice coil): 0.54 mH
• Qes (electrical quality): 0.68
• Qts (overall quality): 0.65
• Vas (equivalent volume): 50.9
• Mms (moving mass): 31 g
• BL (power factor): 12.8 T/m
• Xmax (maximum displacement): 0.8 mm
• Cms (elasticity of the suspension): 0.13 mm/N
• Sd (membrane area): 519.5 cm²
• Weight: 4,54 kg

The G12M Greenback is perhaps the definitive vintage Celestion ceramic magnet guitar speaker. Developed in the mid-sixties, it was quickly adopted by players like Hendrix, Clapton, Beck and Page, who typified the louder and more aggressive blues rock playing styles that came to characterize that era.The G12M-65 Creamback produces the familiar woody G12M tone, but handles greater power making it ideally suited for today's amps, when a vintage tone is desired. The increased power handling brings with it low end grunt complementing the warm and vocal mid range, crunchy upper- mids and sweet, refined highs.

General Specifications

• Nominal diameter: 12", 305mm
• Power rating: 65Wrms
• Nominal impedance: 8Ω & 16Ω
• Sensitivity: 97dB
• Chassis type: Pressed steel
• Voice coil diameter: 1.75", 44.5mm
• Voice coil material: Round copper
• Magnet type: Ceramic
• Magnet weight: 35oz, 0.99kg
• Frequency range: 75-5000Hz
• Resonance frequency, Fs: 75Hz
• DC resistance, Re: 6.7Ω & 13.1Ω

Mounting Information

• Cut-out diameter: 11.1", 283mm
• Diameter: 12.2", 309mm
• Magnet structure diameter: 5.9", 150mm
• Mounting slot dimensions: 0.31", 7.9mm Ø
• Mounting slot PCD: 11.7", 297mm
• Number of mounting slots: 8
• Overall depth: 5.1", 130mm
• Unit weight: 7.9lb, 3.6kg

SCI R13-29B High Current DPDT On-On Toggle Switch

The SCI R13-29B is a high current DPDT toggle switch (double pole double throw), designed for use in high current applications.

Specifications

• Type: Toggle switch with metal lever
• Design: 2-Pole ON-ON switch
• Mounting Ø: 12.2 mm
• Switching capacity: 15A@125VAC / 10A@250VAC
• Switch type: DPDT (double pole double throw)
