Hammond Diecast 1590BOR - ORANGE

• 1x internal and 1x external thread
• Thread size: M3
• External thread: 6.0 mm
• Internal thread: 3.0 mm
• Material: galvanised steel
• Length: 5 mm

•  Powerful, clear sound with the transmission of any instrument signals
•  Dual shielding by Cu mesh screen and conductive carbon screen
•  Highly flexible and easy to reel because of its fine single litz design
•  Extremely durable and rugged due to LONGLIFE COMPOUND jacket

•  High-quality guitar lead for stage & studio
•  Unbalanced cable for all string instruments, keyboards, samplers, mixing desks etc.

• Construction LI2Y(LS)CY 1x0,50mm²
• Jacket, diameter LLC (Long Life Compond) 5,9 mm
• AWG 20
• Inner conductors 1 x 0,50 mm²
• Copper strand per conductor 28 x 0,15 mm
• Conductor insulation Foam/skin-PE 2,8 mm
• Shielding copper spiral tin-plated + semiconductor
• Shielding factor 100 %
• Temperature range min. -25 °C
• Temperature range max. 60 °C
• Fire load per m 0,27 kWh
• Weight per 1 m 4 g
• Color black

• Capac. cond./shield. per 1 m 88 pF
• Cond. resistance per 1 km 90 Ohm
• Insulation resist. per 1 km  1 MOhm

• Spot welded heavy duty construction chassis.
• Natural finish as shown above - protected through manufacturing and shipping with a plastic skin cover to ensure a high quality finish.
• Optional bottom plates are punched with 4 holes (Chassis requires drilling to install optional bottom plates).
• Hardware not provided, please order separately
• Size: 203 x 102 x 51 mm

Files:

• Datasheet

Relays, type Finder Dual-In-Line-Relais 2,0 A
for low breaking capacity

• Compact dimensions: 20.3 x 10.1 x 11.4 mm, grid according to wiring diagram
• Function: 2 x changeover contacts
• Constant/inrush current: 3.0 A/2.0 A
• Rated/switching voltage: 125 VAC/250 VAC
• Breaking capacity AC 1/AC 15 (230 V): 125 VA/25 VA
• Switching current DC 1:    2.0 A/30 V, 0.3 A/110 V
• Minimum switching load: 10 mW (0.1 V/1.0 mA)
• Contact material: AgNi+Au (5.0 µm)
• Useful mechanical life DC: 10 x 10 exp6 switching cycles
• Electrical life AC 1: 100 x 10 exp3 switching cycles
• Insulation coordination EN 61810-5: 1.2 kV/2
• Electric strength coil/contact (1.2/50 µs): 1.5 kV
• Response/release time: 6.0 ms/2.0 ms
• Ambient temperature: –40 to +85 °C
• Relay protection class: RT III
• Certifications: CSA, UL, GOST

• Datasheet

• Tube-Town EZ-Board Twin Relais PCB for channel switching etc.
• Size: 50 x 44,5 mm
• Material: 1,6 mm FR4
• Solder mask: schwarz

For the use with Finder Relais type 30.22.9xx  (or relais with similar pin layout).

•  Powerful, clear sound with the transmission of any instrument signals
•  Dual shielding by Cu mesh screen and conductive carbon screen
•  Highly flexible and easy to reel because of its fine single litz design
•  Extremely durable and rugged due to LONGLIFE COMPOUND jacket

•  High-quality guitar lead for stage & studio
•  Unbalanced cable for all string instruments, keyboards, samplers, mixing desks etc.

• Construction LI2Y(LS)CY 1x0,50mm²
• Jacket, diameter LLC (Long Life Compond) 5,9 mm
• AWG 20
• Inner conductors 1 x 0,50 mm²
• Copper strand per conductor 28 x 0,15 mm
• Conductor insulation Foam/skin-PE 2,8 mm
• Shielding copper spiral tin-plated + semiconductor
• Shielding factor 100 %
• Temperature range min. -25 °C
• Temperature range max. 60 °C
• Fire load per m 0,27 kWh
• Weight per 1 m 4 g
• Color black

• Capac. cond./shield. per 1 m 88 pF
• Cond. resistance per 1 km 90 Ohm
• Insulation resist. per 1 km  1 MOhm

• DC female, female, panel mount
• 0.5A 30 VDC, 3 pins
• Size 5.5 x 2.1mm
• Contact Resistance: < 0.03 Ohm
• Insulation Resistance: > 100 MOhm
• Pack of 5 pcs
