Hammond 290JX Power for Marshall JCM900 - 100 Watt

• Nominal Diameter: 10 " / 254 mm
• Voice Coil: 1.5 " / 38.1 mm
• Overall diameter: 256.8 mm
• Pitch Circle Diameter: 243.8 mm
• Section Diameter: 231.8 mm
• Diameter of fixing holes: 5.7 mm
• Depth: 104 mm
• Nominal Impedance: 8 Ohm(s)
• Nominal Load Capacity: 75 W
• Sensitivity (1 W / 1 m): 98.7 dB
• Frequency response: 100 - 6000 Hz
• Voice Coil Material: copper
• Magnet: Ferrite
• Depth of the magnetic gap: 6.35 mm

• Fs (Resonance Frequency): 97 Hz
• Re (DC resistance): 7.49 Ohm(s)
• Qms (mechanical quality): 17.78
• Le (inductance of the voice coil): 0.56 mH
• Qes (electrical quality): 1.21
• Qts (overall quality): 1.13
• Vas (equivalent volume): 26.4
• Mms (moving mass): 17 g
• BL (power factor): 8 T/m
• Xmax (maximum displacement): mm
• Cms (elasticity of the suspension): 0.16 mm/N
• Sd (membrane area): 344.9 cm²
• Weight: 2,45 kg

Custom Shop Faceplate, Acryl Reverse, laser engraved
The engraved surface becomes transparent and must then be filled with paint. Just like the ProReverse but with a glossy surface. Looks very noble!

• Material: 1,5 mm Acryl Reverse - GLOSSY
• Working area: see option list
• Colors:  see option list
• Engraving: Yes
• Cutting: Yes
• Resolution: max. 500 dpi
• Machining: Laser
