Fuse 5 A slow blow

• High Power Resistor
• Rating: 8.2 Ohms / 5%
• Power: 100 Watt / 40 Watt without heat sink
• Size: 64 x 47 mm
• Aluminium Chassis
• Norm: MiL-R-18546 E (RE 70)

Great for attenuators, power soaks and dummy loads
Very low background noise
RoHS Compliant

• Rated Voltage: 250 VAC
• Contact caps: nickel-plated brass
• Size: Ø 5 mm x 20 mm

NL4MPXX

4 pole chassis connector, black D-size flange, countersunk thru holes, 3/16" flat tabs
The state-of-the-art chassis connector for loudspeaker / amplifier applications. They feature a unique locking system, robust plastic housing and high current silver plated contacts.

Features & Benefits

• Contact resistance: ≤ 2 mΩ
• Dielectric strength: 2.8 kVac
• Insulation resistance: >0.1 GΩ (after dampheat)
• Rated current per contact: 25 A rms continuous (audio rating signicantly higher, depending on signal)
• Rated voltage: 250 V ac
• Attention: speakON is NOT to be used as an AC mains or power supply connector!
• Lifetime: > 5000 mating cycles
• Termination: 3/16" (at tabs (e.g. NLFASTON)
• Locking device: Quick Lock
• Chassis shape: D
• Layout standard hole position, thru holes

Files:

• Datasheet

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 22 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 100 µF
• Voltage Rating: 100 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 30 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 47 µF
• Voltage Rating: 450 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial
