Fender® HotRod Deluxe Pot 250k 30A log - Treble

65 Twin Reverb Potentiometer
Fender®  Part # 003-7596-000

4 tubes, matched as quad

Mullard reincarnated. With the new EL34EH, Marshall amp owners can recreate the balanced tone, deep, tight bass, sweet mids, and well-defined highs of the original equipment Mullards. Innovative design and precision construction give the EL34EH exceptionally smooth and an ideal balance of pleasing even-order harmonics while virtually eliminating undesirable odd-order harmonics.

Files:

• Datasheet

• Optical side indicated by the dot

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 100 µF
• Voltage Rating: 350 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 37 mm
• Termination Style: axial

• Type: Multisection Capacitor
• Capacitance: 50 + 50 µF
• Voltage Rating: 500 V
• Tolerance: - 10% / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 35 mm x 50 mm
• Termination Style: radial, solder lugs

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 10 µF
• Voltage Rating: 450 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 30 mm
• Termination Style: axial

• +/- 5% tolerance
• -55° C to 240° C operating range
• Max 500 V
• Excellent flame retardant coating
• Different manufacturers

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 22 µF
• Voltage Rating: 450 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 16 mm x 30 mm
• Termination Style: axial

Resistor, Metal Oxide 5 Watt

• +/- 5% tolerance
• -55° C to 240° C operating range
• max 500 V
• Excellent flame retardant coating
• Small Size

2 tubes, matched as pair

The 6L6WXT+ features larger plate dimensions and 20 percent higher output than the Sovtek 5881WXT. Extremely low noise and a excellent detailed and harmonic sound, plenty of power and very easy to handle - even while using in "hot" setups.
