Very balanced vintage sound with a bit of "country honk" and hints of classic blues sounds.
General
- Product type Loudspeaker chassis
- type guitars
- nominal diameter 10 "
- nominal diameter 254 mm
- voice coil 1,5 "
- voice coil 38 mm
- total diameter 257 mm
- bolt circle diameter 244 mm
- cutout diameter 232 mm
- diameter mounting holes 5.7 mm
- depth 107 mm
- nominal impedance 8 Ohm
- nominal power handling 75 W
- sensitivity (1 W / 1 m) 98.8 dB
- frequency response 70 - 5000 Hz
- material voice coil copper
- magnet ferrite
- Magnet gap depth 8 mm
Thiele & Small Parameter
- Fs (resonance frequency) 105 Hz
- Re (DC resistance) 7.6 Ohm
- Qms (mechanical quality) 13.27
- Le (voice coil inductance) 0.37 mH
- Qes (Electrical Q) 1.05
- Qts (Total Q) 0.98
- Vas (Equavilent volume) 27
- Mms (Moving mass) 16.3 g
- BL (force factor) 8.8 Tesla/meter
- Cms (suspension compliance) 0.14 mm/N
- Sd (diaphragm area) 366 cm²
- Weight 2.376 kg
