Classic British rock guitar tone. Very mellow, but with lots of definition and rich tonal harmonic balance. Medium break-up modes. Very smooth.
Coloration : A very balanced speaker with lots of definition and rich harmonic detail. More mellow than most Red Coats.
Genre : Classic Rock and Blues
Specification
- Nominal Diameter: 12 " / 304.8 mm
- Voice Coil: 1.75 " / 44.5 mm
- Overall diameter: 305.5 mm
- Pitch Circle Diameter: 294.3 mm
- Section Diameter: 278.1 mm
- Diameter of fixing holes: 6.4 mm
- Depth: 154 mm
- Nominal Impedance: 8 Ohm(s)
- Nominal Load Capacity: 120 W
- Sensitivity (1 W / 1 m): 100.9 dB
- Frequency response: 80 - 5000 Hz
- Voice Coil Material: copper
- Magnet: Ferrite
- Depth of the magnetic gap: 7.92 mm
Thiele & Small Parameter
- Fs (Resonance Frequency): 89 Hz
- Re (DC resistance): 6.37 Ohm(s)
- Qms (mechanical quality): 11.98
- Le (inductance of the voice coil): 0.64 mH
- Qes (electrical quality): 0.93
- Qts (overall quality): 0.77
- Vas (equivalent volume): 39.4
- Mms (moving mass): 30 g
- BL (power factor): 11.5 T/m
- Xmax (maximum displacement): 0.8 mm
- Cms (elasticity of the suspension): 0.1 mm/N
- Sd (membrane area): 519.5 cm²
- Weight: 4,58 kg
