Elektrolyt 330 µF @ 63 Volt

• 2+1 Solder lugs
• lugs brass, tinned

Active, serial FX-Loop for a subsequent installation in an existing tube amplifier
The FX-Loop works with  two LND150 in the send and in the return stage. The send and return level can be adjusted to their optimal value with two potentiometers. The Loop works with the present high voltage of the amplifier.
It has two inputs for low and high signal levels.

Input Levels:
InA: 30 - 60 Vpp, max. 65 Vpp
InB: 10 - 15 Vpp, max. 18 Vpp

The FX-Loop utilize POTENTIALLY FATAL HIGH VOLTAGES.
Seek help from a competent technician if you are in any way unfamiliar with high voltage circuits.
Use at your own risk.

Files:

• Documentation

2 tubes, matched as pair

5881 Tube by JJ

Files:

• Datasheet

DOUBLE ANODE RECTIFYING TUBE
GZ34S is 5AR4 octal base rectifier diode. It provides strong current output. Suitable for all Hi-Fi and Guitar amplifiers.

Files:

• Datasheet

TT PX45 - a  PX18 in combination with the powerstage of the JTM45

Set of componentes for building the TT TT PX45 Guitar Amp.
Please visit the >>Project page for more infos about the amp, schematics and layout.

INCLUDED:

• Transformers
  • Power: tt-jtm45-pw
  • Output: tt-otjtm45D, Dual-Primary
• Resistors
• Capacitors
• Jacks
• Light
• Wires
• Board
• Switches
• Tubes (12AX7 / ECC83 and EL34)
• Fuses & Fuesholder

NOT INCLUDED:

• Headshell
• Chassis ch045
• Knobs
• Faceplate

To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it then don't build it.
THIS IS NOT A BEGINNERS PROJECT !

• Type: Multisection Capacitor
• Capacitance: 32 + 32 µF
• Voltage Rating: 500 V
• Tolerance: - 10% / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 35 mm x 50 mm
• Termination Style: radial, solder lugs

Resistor, Metal Oxide 5 Watt

• +/- 5% tolerance
• -55° C to 240° C operating range
• max 500 V
• Excellent flame retardant coating
• Small Size

2 tubes, matched as pair

Rugged and wonderful-sounding Power Beam tetrode that performs flawlessly at up to 475 volts. Great replacement for single-ended amps such as Fender Champ, or high plate voltage amps like the Fender Deluxe Reverb.

• Specially developed cathode coating
• Tri-alloy plate material
• Carefully aligned grid

Mundorf MLytic HV Dual Chamber Capacitor 47-47µF @ 450 V

• Capacity: 47+47 µF ±20 %
• Rated Voltage: 450 Volts DC
• Dimensions: Ø30xL50 mm
• Terminals: Ø1.40xL50 mm
• Temperature Range: -25°C/-13°F...+105°C/+220°F
• Conductor Material: Aluminum Foil
