EHX Oil Capacitor 0,001 µF/600 V axial

Description

EHX Oil Capacitors are oil impregnated, polyester capacitors that are enclosed in aluminum cylindrical cans and hermetically sealed for superior performance and durability. Impregnating the capacitors in oil eliminates air bubbles between the dielectric and foil that could affect their stability during operation. This enables the capacitors to operate over a wide temperature range with a very tight tolerance.
Originally, oil capacitors were only used in military and precision equipment as well as Hi-Fi audio. Due to their rich, natural tone, they are now widely used in guitars and guitar amplifiers. EHX Oil Capacitors have a balanced, detailed sound with a smooth, vintage top end. They will make any guitar or amplifier more responsive, touch sensitive, and refined.

Spezification:

Capacitance: 0,001 µF
Voltage Rating: 600 V
Dimensions: Ø 11 mm x 24 mm
Termination Style: axial

Information about the manufacturer

Herstellerinformationen | Manufacturer Information

New Sensor Corporation, 32-33 47th Avenue, Long Island City, NY 11101, USA

EU-Wirtschaftsakteur | EU Economic Operator
Tube-Town GmbH, Rumbergring 37, 66969 Lemberg, Germany, info@tube-town.de
