Capacitor Clamp 40 mm

• Type: Cancap
• Capacitance: 40 + 20 + 20 + 20 µF
• Voltage Rating: 500 V
• Tolerance: -10 % / +30 %
• Operating Temperature Range: - 25°C / + 70 °C
• Dimensions: Ø 40 mm x 50 mm
• Termination Style: radial, solder-lugs

• Type: Multisection Capacitor
• Capacitance: 50 + 50 µF
• Voltage Rating: 500 V
• Tolerance: - 10% / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 35 mm x 50 mm
• Termination Style: radial, solder lugs

• Type: Metalized Polyester Film Capacitors
• Voltage Rating: 400 V
• Tolerance: +/- 10%
• Operating Temperature Range: - 40°C / + 85 °C
• Termination Style: axial

4 tubes, matched as quad

Tung-Sol 7027A Reissue, Beam Power Pentode. Strongly committed to quality manufacturing, Tung-Sol tubes have always been known for their reliability and great tone.

Remake of a 12AY7 / 6072. Smooth sound, great for fender-like amps.

Files:

• Datasheet

4 Tubes matched as quad
The JJ 6L6 is very popular because of its warm sound.

Files:

• Datasheet

4 tubes, matched as quad

Improved JJ EL34, with a modified cathode.
Hint: if you replace an EL34 with an E34L you should also check the bias.

Files:

• Datasheet

6SN7 Rebuild

Files:

• Datasheet

• Metalfilm Resistor RN65D
• Very low noise (- 40 dB)
• Very low voltage coefficient (5 ppm/V)
• Military-Spezification
• Tolerance: 1 %
• Power Rating:: 0.5 W (1/2 W)
• Voltage Rating: 350 V
• Temperature Coefficient:: +/- 100 PPM / C
• Series: CMF (Military RN, RL)
• Operating Temperature Range: - 65 C to + 175 C
• Dimensions: 4.57 mm Dia. x 4.57 mm W x 14.27 mm L
• RoHS: NO

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 47 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 21 mm x 37 mm
• Termination Style: axial

1N5359B, Zener diode,

5.0 W,

24 V,

CB417

• Specification: ½ Watt, axial
• Temperature Range: -55°C to +125°C
• Tolerance: 10%
• Max. Operating Voltage: 350 V
• Size: l=9.5 mm, d=3.6 mm
