Mallory 150's 0,22 µF / 630 VDC
Mallory 150's 0,22 µF / 630 VDC
Mallory 150's 0,22 µF / 630 VDC

Mallory 150's 0,22 µF / 630 VDC

Art.Nr.:
cma22
auf Lager und sofort lieferbar. Lieferzeit ca. 2-5 Tage* auf Lager und sofort lieferbar. Lieferzeit ca. 2-5 Tage*
RoHs:
konform
Gewicht (brutto):
0.004 kg je Stück
3,25 €

inkl. MwSt. zzgl. Versand

Merken
Frage stellen
Beschreibung
Mallory Type 150 is a general purpose capacitor for use in blocking, bypass, decoupling, smoothing and some timing applications.
  • Epoxy end fill meets UL94V-0
  • Non inductively wound
  • Flame retardant outer wrap meets UL510
  • Non polar
Specifications:
  • Operating Tempeature Range: –55 ºC to +125 ºC (derate linearly to 50% rated voltage at 125 ºC)
  • Dielectric Withstand Voltage: .6 x rated voltage for 2 s @ +25 ºC ±5 ºC
  • Dissipation Factor (DF): tgd x 10–4 at +25 ºC ±5 ºC
  • Insulation Resistance: 10,000 MO x µF, 30,000 MO Min.
  • Self Inductance: 1 nH max. per 1 mm lead and body length
  • Life Test: 1000 hrs @ 85 ºC 1.25 x Vn
  • Damp Heat Test: 95% RH @ +45 ºC for 21 days
  • Soldering: 260 ºC ±5 ºC for 10 s ±1 s
  • Long Term Storage Stability: ?C/C = ±3% after 2 years
Dokumente
CDE 150 Serie Datenblatt  (121.37 KB)
Kundenrezensionen

Wesentliche Informationen zu Kundenbewertungen Wir überprüfen nicht, dass die veröffentlichten Bewertungen von solchen Verbrauchern stammen, die die bewerteten Waren oder Dienstleistungen tatsächlich genutzt oder erworben haben. Es werden alle Bewertungen, d. h. positive und negative veröffentlicht. Es werden keine unsachlichen, beleidigende oder nicht mit dem Produkt zusammenhängende Bewertungen veröffentlicht.

Leider sind noch keine Bewertungen vorhanden. Seien Sie der Erste, der das Produkt bewertet.
